Neo Smartpen M1+

Neo Smartpen M1+ is similar to ordinary pens in terms of size and weight and yet it still has every function from previous Neo N2 and Neo M1.

Neo Smartpen only works with Digital Paper (Ncode imprinted in the pages) – compatible notebooks and paper are available to order upon request.

Availability of each colour options may be subject to change upon quoting/ordering.

Purchase on ATStore


Create a Seamless Transition Between the Analog and Digital

Comfortable in Your Hands, Just Like Normal Pens

M1+ is made of flexible materials including, durable glass fibers and reinforced plastics.


159 mm


10.4 mm


17.9 g

Simple And Casual Design

The compact and simple design of Neo Smartpen M1+ allows a more uninterrupted writing experience than ever.

What’s in the box

  1. Product Case
  2. Neo Smartpen M1+
  3. Charging Cable
  4. Ballpoint Pen Nib
  5. Manual

A Smooth But Sturdy Pen Body

The Neo Smartpen M1+ has employed fiberglass and reinforced plastic material for a sturdy body to protect against external shock.

Product Specification

  • Support: Android Lollipop 5.0 or newer (Bluetooth 2.1 or better) / iOS 8.1 or newer (Blutetooth 4.0 LE or better) / Windows 10 (Bluetooth 2.1 + EDR or better)
  • Bluetooth Connection:  Bluetooth 4.2 (CLASSIC/BLE)
  • Memory: Internal 100MB memory
  • Battery: Rechargeable Li-po battery 3.7V/280mAh
  • Charging Time: About 90 minutes
  • Size & Weight: Length 149.6mm (excluding pen cap), Thickness 10.4~10.9mm / 17.6g (excluding pen cap)
  • Pen Lead: Standard D1 type

Smarter Neo Smartpen

The Neo smartpen M1+ is equipped with the automatic ON/OFF function. It automatically turns on the power when opening the pen cap, and when not using it, it is converted to the standby power mode. This not only it helps to manage battery and power consumption, but it also provides a comfortable usability.

  • Charging: Micro USB cable
  • Charging Time: About 90 minutes
  • Standby Mode: 125 days
  • Continuous Use: About 6.5 hours
  • Typical Writing: About 17 hours
  • Offline Mode: Possible to store about more than 1,000 A4 pages

Neo Smartpen is compatible with standard D-1 Type pen tip

To replace the pen tip, remove the pen tip from the Neo Smartpen and place the refill lead in the same way.

Please use the Neo smartpen with verified pen tip!

When using refill pen tip other than the verified ones, it may cause deterioration of the writing recognition rate of the Neo smartpen or a defect.

Ncode™ Technology

Ncode™ is the combination of lines and symbols which create a pattern that expresses an unique code for every location of the page.

Here’s how it works:

  1. Take notes with Neo smartpen M1 on Digital Paper
  2. M1 captures the Ncode™ of the page you write on
  3. M1 transfers the code data to the connected smart device. You can edit and share your handwritten notes with our app Neo Notes.



Black, Grey, Navy Blue

Connection Type

Bluetooth, Micro-USB

Bluetooth Version

Bluetooth 4.2 (Classic/BLE)


Rechargeable Li-Po Battery 3.7V / 280mAh
(Charging Time: About 90 minutes via Micro-USB port)


Android 5.0 (Lollipop) or newer – Bluetooth 2.1 or better
iOS 8.1 or newer – Bluetooth 4.0 LE or better
Windows 10 or newer – Bluetooth 2.1 + EDR or better
